|Type:||Horizontal reciprocating single-acting triplex piston pump||Cylinder Dia. (mm):||70|
|Stroke (mm):||70||Rated Power (kW):||11kw （Motor）|
|Volumetric Efficiency (%):||95||Overall Efficiency (%):||78|
|Input Torque (Nm):||150||Input Speed (r/min):||610|
|Suction Pipe Dia. (mm):||51||Discharge Pipe Dia. (mm):||32|
|Dimension (L × W × H) (mm):||1830 × 800 × 1030 (equipped with motor)||Weight (kgs):||325 (equipped with hydraulic motor)|
Simple Operation BW-160 /10 Portable Triplex Mud Pump For Geological Prospecting
BW 160/10 triplex mud pump is one of the primarily utilized equipment for geological prospecting. During core drilling, this triplex reciprocating pump provides the drilling hole with enough slurry or cleaning water and makes it circulate in the drilling hole to carry the debris up to the earth surface, so as to clean the bottom of the drilling hole as well as cool and lubricate the drilling tools. In this way, the wall of the drilling hole can be protected and the drilling working will be faster. The performance of mud-pump directly affects the efficiency of drilling and safety in production, so users must read the user’s guide before utilizing the pump.
BW 160/10 three plunger mud pump is a new member of our portable mud pump family. It is a horizontal single acting triplex reciprocating piston pump. This triplex mud pump is small and light, and it enjoys long service life, simple operation and reliable performance. Additionally, it is equipped with a number of interchangeable parts and standard parts to facilitate assembly and repair. This triplex reciprocating pump is extensively applied to geological and engineering prospecting within a hole depth of 1,000m in industries like railway, water conservancy, metallurgy, building, geology, etc.
Electromotor-driven and diesel engine-driven triplex mud pump are available to satisfy your particular needs.
We have continuously adhered to improve the performance of our mud pump. If you find any discrepancy between the user’s guide and the real product, please refer to the real product.
Triplex reciprocating pump with four different levels of displacement and pressure is available to suit for drilling working of different diameters. It is also designed for core drilling, chemical engineering,oil well drainage, soft foundation grouting, etc.
1 Standard, identical and interchangeable parts of pump body, crankshaft, connecting rod, crosshead, pump head, etc.
2. Long service life and high reliability of high wear parts.
3. Adopts new concepts in design and uses new structure, materials and processes.
4. Compact in structure, light in weight and attractive in appearance.
5. Driven by hydraulic motor, electromotor or diesel engine.
|Type||Horizontal single-acting triplex reciprocating mud pump|
|Cylinder Dia. (mm)||70|
|Pump Speed (rpm)||200||132|
|Volumetric Efficiency (%)||95|
|Overall Efficiency (%)||78|
|Input Torque (Nm)||150|
|Input Speed (r/min)||610|
|Rated Power (kW)||11 (motor)|
|Suction Pipe Dia. (mm)||51|
|Discharge Pipe Dia. (mm)||32|
|Dimension (L *W * H) (mm)||1830 * 800 *1030 (equipped with motor)|
|900 *750 *600 (equipped with hydraulic motor)|
|Weight (kgs)||490 (equipped with motor)|
|325 (equipped with hydraulic motor)|
